Golden Motor Cars
E Revolution Co Ltd is moving forward with technology & has a range of Electric vehicle components available in Thailand. If you want to build your own supercar or just make a small EV as a project, we can help. We use the PayPal secure online payment system & deliver to your door !
Powered by a Golden Motor 5 KW High Power BLDC Motor
Model: HPM5000A
Features :
Compact design, Water resistent, Stainless Steel Shaft, Self Cooling Fan
Voltage: 48V / 72V / 96V / 120V
Rated Power: 3KW - 7.5KW
Efficiency: 91%
Phase Resistance (Milliohm): 6.2 / 48V ; 12.0 / 72V ; 36.0 / 120V
Phase Induction(100KHZ): 68uH / 48V ; 154uH / 72V ; 504uH / 120v
Speed: 2000-6000rpm (customizable)
Weight: 11Kgs
Casing: Aluminium
Length (height): 126mm Diameter: 206mm
Keyway size: 5mm(W) x 43mm(L) x 19mm(D:22.3mm
Applications : Electric car, electric motorcycle, electric tricycle, electric golf carts, fork lift, electric boats
Powered by a Golden Motor 10 KW High Power BLDC Motor Air Cooled
Model: HPM-10KA
48 - 72 - 96 - 120 volts
Rated Power 8 -20 KW
Efficiency: 91%
Phase Resistance (Milliohm): 3.1 - 48V 6.0 - 72V 18.0 - 120V
Phase Induction (100KHZ) 34uH - 48V 77uH - 72V 252uH - 120v
Speed: 2000-6000rpm (customizable)
Weight 17 Kgs
Casing: Aluminium
Length (height): 170mm Diameter: 206mm
Keyway size: 6.4mm(W) x 45mm(L) x 21.7mm(D:25.4mm
High Power 20 KW BLDC Motor
Model: HPM-20KW
Voltage: 72 - 96 - 120 volts
Rated power: 20 - 25 KW
Peak power: 50 KW
Speed: 3200-6000rpm
Rated torque: 80 Nm
Peak torque: 160 Nm
Efficiency: >90%
Dimensions: 30x30x25cm
Weight: 39kgs
Cooling: liquid cooling
